Automatic Horizontal Buoy Premade Pouch Doypack Packing Packaging Machine

Application:

This machine is designed for packing block material such as buoy, snacks, loose tea, dry food, bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuits, peanuts, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

E-mail: info@landpacking.com

Tel/Whtasapp: +86 18688215960

Chat Now Send Email View video

Features:

Application:

Videos Introduction:

Specification:

Working Process:

Features:

1.Automatic feeding product, Speed adjustable.

2.High speed and precision multi heads weigher dosing system.

3.Famous electric parts oversea, Top quality.

4.Customized station can adjust for flat bottom bag and doypack bag.

5.Twice sealing, Make bag more beautiful.

Application:

This machine is designed for packing block material such as buoy, snacks, loose tea, dry food, bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuits, peanuts, etc.

Videos Introduction:

Specification:

Item	Automatic Horizontal Buoy Premade Pouch Doypack Packing Packaging Machine
Brand	Landpack
Model	LDSP-160	LDSP-160Y	LDSP-210	LDSP-260
Bag Type	3-side sealing bag, 4-side sealing bag, Doypack, Box Pouch, Zipper Pouch, Stand Up Pouch, Stand Up Pouch With Hole, Kraft Paper Bag, Side Gusset Bag, etc.
Bag Size	110-230mm80-160mm(LW)	70-100mm110-230(LW)	100-210mm/110-320mm(L*W)	100-260mm/110-320mm(L*W)
Filling Range	10g-100g	10g-100g	10g-1kg	10g-3kg
Packing Speed	20-45bags/min	25-50bags/min	20-50bags/min	20-50bags/min
Machine weight	800KG	800KG	900KG	1000KG
Total Power	2.0KW
Work Flow	1. Giving bag 2. Pick up the bag(coding) 3. Open the bag up and down 4. Filling 5. Heating sealing 6. Output of product
Dimensions	1750mm1285mm1360mm(LWH)		2140mm1366mm1360mm(LWH)
Collocation	Screw metering, screw elevator

Working Process:

1、Manual feeding product

2、Automatic bag giving

3、Bag Opening

4、Auto Filling

5、Auto Sealing

6、Output
