Automatic Granule Food Horizontal Premade Pouch Packing Machine With Metal Detector

Application:

It can automatically package various materials such as solids, liquids, sauces, creams, powders, and granules.According to the requirements of different customers, the first-class professional automatic packaging machine can be tailored to package a variety of bag types.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Working Process:
Inquiry
Features:

1. Efficient: filling, sealing, cutting, heating, date / lot number achieved in one time.

2. Intelligent: Packing speed and bag length can be set through the screen without part changes.

3. Profession: Independent temperature controller with heat balance enables different packing materials.

4. Characteristic: Automatic stop function, with safe operation and saving the film.

5. Convenient: Low loss, labor saving, easy for operation and maintenance.
Application:

1.Food:Candy,Beans,Chips,Popcorn,Pasta,Corn,Rice,cake,Jelly,Cookies,Cheese,Peanuts,Coffee Creamer,Almond,etc.

2.Daily necessities:Mothballs,Disposable Mask,Buttons,etc.

3.Hard&Ware:O ring,Screw,Dowel,etc.

4.Medical:Pill,Medicine,etc.

Videos Introduction:
Specification:
Item Automatic Granule Food Horizontal Premade Pouch Packing Machine With Metal Detector
Brand Landpack
Model LDSP-160 LDSP-160Y LDSP-210 LDSP-260
Bag Type 3-side sealing bag, 4-side sealing bag, Doypack, Box Pouch, Zipper Pouch, Stand Up Pouch, Stand Up Pouch With Hole, Kraft Paper Bag, Side Gusset Bag, etc.
Bag Size 110-230mm*80-160mm(L*W) 70-100mm*110-230(L*W) 100-210mm/110-320mm(L*W) 100-260mm/110-320mm(L*W)
Filling Range 10g-100g 10g-100g 10g-1kg 10g-3kg
Packing Speed 20-45bags/min 25-50bags/min 20-50bags/min 20-50bags/min
Machine weight 800KG 800KG 900KG 1000KG
Total Power 2.0KW
Work Flow 1. Giving bag 2. Pick up the bag(coding) 3. Open the bag up and down 4. Filling 5. Heating sealing 6. Output of product
Dimensions 1750mm*1285mm*1360mm(L*W*H) 2140mm*1366mm*1360mm(L*W*H)
Collocation Screw metering, screw elevator
Working Process:

1. Slope elevator delivers the product to the weigher

2. 10-head 2.5L weigher to measure the weight automatically

3. Automatically bag feeding

4. Ribbon code print

5. Automatically bag opening

6. Automatically filling and vibation

7. Sealing

8. Output

9. Finished product conveyor delivers the finished bag to outside

10. Metal detector and weight detector
