Horizontal Premade Pouch Packing Machine For High Visicocity Tuna Meat Pet Food Packing

Application:

This Horizontal Premade Pouch Packing Machine With Rotor Pump, It is suitable for liquid standing bags, pre-made bags, zipper bags packaging, such as tuna meat, pet food, juice, cream, jam, laundry detergent, hand soap, sauces, honey, milk, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Features:

1.Independent Control Box for the Hopper for 8 memory of the Filling capacity.

2.Vertical Bag Feeder for more quantity speed.

3.5 leafs rotor measuring pump for high viscocity product like tuna meat ,honey ,chocolate cream.

4.100Liters Heater And stir hopper for easy clean.

5.Adpoted Simens PLC +Touch screen for easy operate.

6.Customized Irregular Anti-Leakage Filling Nozzle.

7.Second Times Sealing keep sealing tightly and beautiful.

Application:

This Horizontal Premade Pouch Packing Machine With Rotor Pump, It is suitable for liquid standing bags, pre-made bags, zipper bags packaging, such as tuna meat, pet food, juice, cream, jam, laundry detergent, hand soap, sauces, honey, milk, etc.

Samples:

Specification:

The Main Technical Parameters of Horizontal Premade Pouch Packing Machine For High Visicocity Tuna Meat Pet Food Packing
Model	LDSP-210L
Packing material	3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc
size	W：110-300 mm
Filling range	10-1000ml
Packing speed	10-45 bag/min（speed is determined by the product filling quantity）
Average precision	≤ ±1%
Total power	2.5KW
Weight	900 KG
Main standard parts	1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system
We can customize the suitable one for you according to your requiredment. Just Tell us : Weight or Bag Size required.

Parts of Horizontal Premade Pouch Packing Machine For High Visicocity Tuna Meat Pet Food Packing
Parts	PLC	Touch Screen	Frequency Conveter	Vacuum Pump	Printer	Main Motor	emperature Controllor
Brand	SIEMENS	SIEMENS	TOSHIBA	ORION	SHENG LONG	EVERGEAR	AISET
Oringin	Germany	Germany	Japan	Japan	China	China	China
Can replace parts as needed

Work Process of Horizontal Premade Pouch Packing Machine For High Visicocity Tuna Meat Pet Food Packing
Safety Measures	1.no bag feeding, no filling and no sealing. 2.no bag opening/open error, no filling and no sealing 3.no filling, no sealing
Product Process	Station 1 Bag Feeding Station 2 Date Printing (option)and Open zipper bag Station 3 Open bag Station 4 Filling Materials Station 5,6,7 :Vibration,Air Removal,Nitrogen Filling,Close Zipper,Hole Punching,Heat Sealing Remark:No.5.6.7.Stations are based on customer requirements for adjusting. Station 8 Heat Sealing and Product Output
Stations are based on customer requirements for adjusting.

Composition:

1. Code printer

2. PLC control system

3. Bag opening device

4. Vibration device

5. Cylinder

6. Electromagnetic valve

7. Temperature controller

8. Vacuum pump

9. Inverter

10. Output system
