Low Cost Stable All-In-One VFFS Packaging Machine LD-420Y

Application:

Suitable for packing and weighing many kinds of products such as: puffy food, shrimp roll,peanut, shrimp chips, popcorn, cornmeal, seed and sugar,etc. which shape is roll, slice and granule.

Details:


Model:LD-520LFS
Film width:180-580 mm
Bag length: 50-280 mm
Bag width: 50-180mm
Diameter of film roll : Max.420mm
Packing speed:10-80bag/min
Measuring range: 50-750 ml
Powder: 220 50/60Hz 2.5KW
Tel/Whtasapp: +86 18688215960
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

PLC computer control system.PLC from Janpan or Germany;

Big touch From Tai wan . Easy to operate and control the machine;

High precise positioning with servo film transporting systerm;

Servo motor from Germany Seimens to ensure stable;

Warn protection function;

The machine will automatically complete all packaging processes from measuring, feeding, filling, Printing, finished bag;

The way of bag making: the machine can make pillow-type bag and standing bag according to customer's requirements.
Application:

Suitable for packing and weighing many kinds of products such as: puffy food, shrimp roll,peanut, shrimp chips, popcorn, cornmeal, seed and sugar,etc. which shape is roll, slice and granule.
Samples:


Specification:
Main main parameter
Packing speed
10-80 bag/min
Bag size
(Width)80-200mm (Length)50-300mm
Bag making mode
Pillow-type bag, standing bag, punch hold and connect
ange of measuring
2000ml
The maximum width of packing film 420mm
Thickness of film 0.04-0.10 mm
Air consumption 400L/min 0.6×105Pa
Main power/voltage 4.0 KW/220V 50-60Hz
Dimension
1720×1030×2254mm
The weight of switchboard
450Kg
Combined Parts:

LD series main frame

Screw metering machine

Screw infeed conveyor

Product conveyor
