High Speed Vertical Form Fill Seal Machine With Measuring Cups Equipment

Application:

Automatic powder form fill seal machine, Suitable for packing the fine powder material. Such as coffee powder, spice powder, milk powder, flour, fruits powder, seasoning, chemical medical powder, etc. It integrates metering, bagging, packing, sealing, date printing.

Details:

Model:LD-320SF

Film width:120-320 mm

Bag length: 50-270 mm

Bag width: 50-150mm

Diameter of film roll : Max.320mm

Packing speed:15-100bag/min

Measuring range: 50-750 ml
Powder: 220 50/60Hz 2.5KW

Features:

The whole machine adopts 3 servo control system, the machine runs smoothly, the action is accurate, the performance is stable, and the packaging efficiency is high

The whole machine adopts 3mm&5mm thick stainless steel sheet metal processing and assembly, running smoothly; and the core components are specially optimized design, and the packaging speed is fast;

The equipment adopts servo-driven film pulling and unwinding to ensure precise film pulling and neat and beautiful packaging bags;

It can be matched with combination weigher, screw, measuring cup, drag bucket, liquid pump to achieve accurate and efficient measurement; (the above functions have been standard in the packaging machine program)

The equipment accessories adopt domestic/international famous brand electrical components, and have been tested by many years of market practice to ensure more stable and durable performance;

The design of the whole machine complies with GMP standards and has passed CE certification.

Application:

Automatic powder form fill seal machine, Suitable for packing the fine powder material. Such as coffee powder, spice powder, milk powder, flour, fruits powder, seasoning, chemical medical powder, etc. It integrates metering, bagging, packing, sealing, date printing.

Samples:

Specification:

Model	LD-320SF
Capacity	20-100 bag/min
Bag size	L:50—170mm， W:50—150mm
Film width	120mm—320mm
Film thickness	0.05—0.12mm
Control system	PLC+Servo Motor+Color Touch Screen; PLC+Servo+Touch screen
Power supply	1N+PE/50HZ/AC220V 4KW
Airconsumption	0.6—0.8Mpa, 0.3—0.5㎥/h
Dimension	L1350W900H1400mm
Equipment Material	Main body 3mm thickness 304 stainless steel frame
Weight	350kg
Description of Main Packaging Process	Pulling film-coding-bag making-measurement-filling (inflating)-sealing (punching)-cutting-packaging finished product output.

Combined Parts:

LD series main frame

Screw metering machine

Screw infeed conveyor

Product conveyor
