You are here: Home > Product > Vertical Form Fill Seal Machine(VFFS)

High Speed Ketchup Sachet Multi Lane Packing Machine

Application:

Suitable for all kinds of paste, viscous liquid packaging, such as ketchup, chili sauce, honey, chocolate sauce, chili sause, cream, juice, shower gel, shampoo etc.

Details:


Model:LDFS720L-8
Film width:480-960 mm
Bag length: 40-120 mm
Bag width: 35-60mm
Diameter of film roll : Max.480mm
Packing speed:35-40bag/min
Measuring range: 50-750 ml
Tel/Whtasapp: +86 18688215960
Features:
Application:
Samples:
Specification:
Packing type:
Inquiry
Features:

Automatically complete all tasks such as measurement, bag making, filling, sealing, batch number printing, cutting and counting.;

Automatic slitting film system, multi-line row and bag sealing at the same time.;

Servo film running system, pneumatic control for horizontal sealing, accurate positioning, remarkable performance and beautiful packaging.;

The dual light source photoelectric detection system is stable and reliable to ensure the integrity of the packaging bag.;

Intelligent PLC control system, stable operation of the machine, convenient and fast operation,;

A variety of automatic alarm protection functions can effectively reduce the loss of materials and ensure work safety.;

Use touch screen to set parameters and support multiple languages.;
Application:

Suitable for all kinds of paste, viscous liquid packaging, such as ketchup, chili sauce, honey, chocolate sauce, chili sause, cream, juice, shower gel, shampoo etc.
Samples:

Specification:

Model

LD-480Y LD-720Y LD-960Y
Track Number 4~6 Track 4~10 Track 4~12 Track
Filling Method 1.Piston pump;   2.Peristaltic Pump
Capacity Max.40 cycle/min
Sachet Size L:45--120mm; W:35-60mm L:45--120mm; W:35-90mm L:45--120mm; W:35-120mm
Film Width & Thickness Max.480mm;0.07-0.1mm Max.720mm;0.07-0.1mm Max.960mm;0.07-0.1mm
Sealing Type 3/4 sides sealing 3/4 sides sealing 3/4 sides sealing
Cutting Type 1. Straight Cutting;    2. Zig Zag Cutting;    3. Continuous Cutting
Air & Power 0.8 mpa  0.8m³/min; 2.8kw 0.8 mpa  0.8m³/min; 4.1kw 0.8 mpa  0.8m³/min; 5.5kw
DIM & WT 950*1470*1750mm; 300kg 1153*1654*1750mm; 400kg 1415*1686*2130mm; 500kg
Packing type:

1.Sealing type:4 sides sealing;

2.Cutting type:Straight cutting; Zig zag cutting; Round cutting; Irregular
