Automatic VFFS Packaging Machine With Linear Weigher LD-620AS

Application:

Suitable to packaging small grain with good uniformity, such as oatmeal, sugar, salt, seeds, rice, sesame, milk powder coffee, etc

Details:


Model:LD-420A/ 580A
Film width:120-520 mm
Bag length: 80-350 mm
Bag width: 60-250mm
Diameter of film roll : Max.320mm
Packing speed:15-60bag/min
Measuring range: 150-2000 ml
Powder: 220V 50/60Hz 2KW
Tel/Whtasapp: +86 17388602385
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

Microcomputer control system adopts double vibration infeeding, importing instrumentation, technology and easy operation.

Due to the sealed balance body with full sta inless steel, it has dustproof and anticorrosive function.

The measure hopper can be disassembled quickly. cleaned and repaired conveniently.

Combine with all kinds of repacking form follow requirements of clients, to ex pand the scop of weighing.

High compatibility. it is easy to combine with other packaging machine.

High precision structure for simple and easy operation and repair.

PLC touch screen, step motor control, easy and accurate to set the bag length.

lt's owns simple circuitry and outstanding function.

The machine completes the whole procedure of filling, bagging, date printing, charging (exhausting) automatically.
Application:

Suitable to packaging small grain with good uniformity, such as oatmeal, sugar, salt, seeds, rice, sesame, milk powder coffee, etc.
Samples:


Specification:
Type LD-420 LD-520 LD-720
Film Width Max.420mm Max.520mm Max.720mm
Bag Length 80-300mm 80-350mm 100-500mm
Bag Width 60-200mm 100-250mm 180-350mm
Film Thickness 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm
Measuring Range 150-1500ml 2000ml 4000ml
Packaging Rate 10-60bag/min 10-60bag/min 10-55bag/min
Power 220V 50/60Hz 2KW 220V 50/60Hz 3KW 220V 50/60Hz 3KW
Machine Size(L*W*H) 1217*1015*1343mm 1488*1080*1490mm 1780*1350*2050mm
Machine Quality About 650kg About 680kg About 750kg
Optional Device 1.Date coding printer, 2.Air-filling device, 3.Punching device, 4.Tear notch device
Combined Parts:

LD series main frame

Screw metering machine

Screw infeed conveyor

Product conveyor
