Automatic Liquid Vertical Form Fill And Seal Machine

Application:

Suitable for packing various kinds of liquid objects, such as oli, water, juice, milk, honey, soysauce, ketchup, tomato sauce, etc.

Details:


Model:LD-420L/ 520L
Film width: Max.520 mm
Bag length: 80-350 mm
Bag width: 60-250mm
Diameter of film roll : Max.320mm
Packing speed:15-60bag/min
Measuring range: 50-750 ml
Powder: 220V 50/60Hz 3KW
Tel/Whtasapp: +86 18688215960
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

Products dosing, Filling, Laminate heat sealable pouch making and sealing.

Stainless steel 304 structure and surface.

Weighing and Packaging PLC & HMI Control Integrated, More stable operation, Easy for parameter setting.

Simple changing of pouch former, to adapt different pouch size requirement.

Intelligent temperature controlling configuration, ensure the artistic and neat sealing.

Configure with packaging film pre-pulling device, to enable stable pouch making.

No film no filling, and easy to change the packaging film.
Application:

Suitable for packing various kinds of liquid objects, such as oli, water, juice, milk, honey, soysauce, ketchup, tomato sauce, etc.
Samples:


Specification:
Model LD-420L LD-520L
Film Width Max.420mm Max.520mm
Bag Length 80-300mm 80-350mm
Bag Width 60-200mm 100-250mm
Range of Measurement     150-1500ml 2000ml
Film Roll Diameter Max.320mm Max.320mm
Packaging Rate 10-60bag/min 10-60bag/min
Power 220V 50/60Hz 2KW 220V 50/60Hz 3KW
Machine Size(L*W*H) 1217*1015*1343mm 1488*1080*1490mm
Machine Quality About 650kg About 680kg
Optional device 1.Date Printing,2.Hole Punching Device,3.Air-filling Device,4.Tear Notch Device
Combined Parts:

LD series main frame

Screw metering machine

Screw infeed conveyor

Product conveyor
