Automatic Multi Lane Liquid Stick Bag Packaging Filling Cartoning Machine Line System

Application:

Multi lane liquid stick packing machine with counting cartooning machine line is suitable for the packaging of various liquid products, such as ketchup, paste, honey, chili sauce, bean paste, instant noodle sauce, cream, milk, butter, water, oil, vinegar, liquid seasoning, shampoo, jelly, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

E-mail: info@landpacking.com

Tel/Whtasapp: +86 18688215960

Chat Now Send Email View video

Features:

Application:

Videos Introduction:

Specification:

Working Process:

Features:

PLC procedure man-machine interface operation

Servo motor control metering pump high precision.

12 lanes filling device increased production capacity

Photoelectric sensor couting fastly and precisely

Application:

Multi lane liquid stick packing machine with counting cartooning machine line is suitable for the packaging of various liquid products, such as ketchup, paste, honey, chili sauce, bean paste, instant noodle sauce, cream, milk, butter, water, oil, vinegar, liquid seasoning, shampoo, jelly, etc.

Videos Introduction:

Specification:

Model	LD-480Y	LD-720Y	LD-960Y
Track Number	4-6 Track	4-10 Track	4-12 Track
Filling Method	1.Piston pump; 2.Peristaltic Pump
Capacity	Max.40 cycle/min
Sachet Size	L: 45-120mm; W: 35-60mm	L: 45-120mm; W: 35-90mm	L: 45-120mm; W: 35-120mm
Film Width & Thickness	Max.480mm;0.07-0.1mm	Max.720mm;0.07-0.1mm	Max.960mm;0.07-0.1mm
Sealing Type	3/4 sides sealing	3/4 sides sealing	3/4 sides sealing
Cutting Type	1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting
Air & Power	0.8 mpa, 0.8m³/min, 2.8kw	0.8 mpa, 0.8m³/min, 4.1kw	0.8 mpa, 0.8m³/min, 5.5kw
DIM & WT	95014701750mm; 300kg	115316541750mm; 400kg	141516862130mm; 500kg

Working Process:

1.Air shaft loading roll film width 1200mm

2.UV sterilization

3.Piston pump metering servo motor control

4.12 Lanes filling device

5.Cylinder control cutting film

6.Automatically counting sachet into box

7.Photoelectric Sensor detect no carton no feeding

8.Ribbon date printer
