High Speed Granules Potato Chips Sachet Packing Machine

Application:

It is suitable for packing for all kinds of grain material, sheet material, strip material and abnormity material which such as candy, melon seeds, chips, peanuts, nutlet , preserved fruit, jelly, biscuit, confect, camphorball, currant, almond, chocolate, fibert, cornp.

Details:

Model:LD-320SF

Filling method:Auger filling by servo motor

Capacity:Max.35 cycle/min

Sachet size:L:50-230mm;W:17-30mm

Film weight&thickness:Max.480mm,0.07-0.10mm

Sealing type:Back sealing/stick bag

Cutting type:1.straight cutting;2.zig zag cutting;3.round cutting

Air&power:0.8Mpa 0.8m3/min;5.5kw


Tel/Whtasapp: +86 18688215960
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

The whole machine adopts 3 servo control system, the machine runs smoothly, the action is accurate, the performance is stable, and the packaging efficiency is high;

The whole machine adopts 3mm&5mm thick stainless steel sheet metal processing and assembly, running smoothly; and the core components are specially optimized design, and the packaging speed is fast;

The equipment adopts servo-driven film pulling and unwinding to ensure precise film pulling and neat and beautiful packaging bags;

t can be matched with combination weigher, screw, measuring cup, drag bucket, liquid pump to achieve accurate and efficient measurement; (the above functions have been standard in the packaging machine program)

The equipment accessories adopt domestic/international famous brand electrical components, and have been tested by many years of market practice to ensure more stable and durable performance;

The design of the whole machine complies with GMP standards and has passed CE certification.
Application:

It is suitable for packing for all kinds of grain material, sheet material, strip material and abnormity material which such as candy, melon seeds, chips, peanuts, nutlet , preserved fruit, jelly, biscuit, confect, camphorball, currant, almond, chocolate, fibert, cornp.

Samples:


Specification:
Model LD-320SF
Capacity 20-100 bag/min
Bag size L:50—170mm, W:50—150mm
Film width 120mm—320mm
Film thickness 0.05—0.12mm
Control system PLC+Servo Motor+Color Touch Screen; PLC+Servo+Touch screen
Power supply 1N+PE/50HZ/AC220V  4KW
Airconsumption 0.6—0.8Mpa, 0.3—0.5㎥/h
Dimension L1350*W900*H1400mm
Equipment Material Main body 3mm thickness 304 stainless steel frame
Weight 350kg
Description of Main Packaging Process Pulling film-coding-bag making-measurement-filling (inflating)-sealing (punching)-cutting-packaging finished product output.
Combined Parts:

ZV series main frame

Screw metering machine.

Screw infeed conveyor

Product conveyor
