Single Station Zipper Pouch Ratory Doypack Packaging Machine For Liquid

Application:

Suitable for liquids premade bags, standing bags, zipper bags packaging  such as jams, laundry detergents, shampoos, sauces, honey, water, fruit drinks, oils, popsicles, etc.

Details:


Machine Type: LDB-300

Bag Material/Bag Type::Multilayer Composite Premade Bag

E.G.: PET/PE)

Size Range: 80mm≤W≤300mm

100mm≤L≤300mm

Speed: 0~15bags/Min

Sealing Type: Straight Grain, Pitch Is 1mm (Optional Reticulate)

Sealing Width: 10mm(5--20mm Can Be Customized)

Voltage: 220V, Single-Phase,50/60HZ, 1.2KW

Mobile Phone/Whatapp: +86 13242108152
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

Wide range of pouches: All kinds of pre-made pouches such as flat and stand-up pouches (with/without zip)

Easy to operate: PLC and color panel, fault indication on the panel.

Easy to adjust: Only about 10 minutes to change different pouches.

Frequency control: Speed can be adjusted by frequency conversion within the range.

Water proof design: The machine surface can be washed down, so easy cleaning and longer useful life.

No pouch/incorrect pouch opening-no fill-no seal, machine alarm.

Machine alarm and stop when the inadequate air pressure.

Safety guards with safety-switches, machine alarm and stop when the safety guards are opened.

Hygienic construction, the product contact parts are adopted sus304 stainless steel.

Imported engineering plastic bearings, no need to oil, no contamination.

Oil-free vacuum pump, avoid the pollution of the production environmental.
Application:

Suitable for liquids premade bags, standing bags, zipper bags packaging  such as jams, laundry detergents, shampoos, sauces, honey, water, fruit drinks, oils, popsicles, etc.
Samples:

Specification:
 Machine Type  LDB-300
 Bag Material/Bag Type  Multilayer Composite Premade Bag
(e.g.: PET/PE)
 Upgradable Bag Type  Gusset Bag, Zipper Bag, Flat Bottom Pouch
(Need additional purchase of functional device)
 Size Range  80mm≤W≤300mm
100mm≤L≤300mm
 Speed  0~15bags/min
 Sealing Type  Straight grain, pitch is 1mm (Optional reticulate)
 Sealing Width  10mm(5--20mm can be customized)
 Voltage  220V, Single-phase,
50/60HZ, 1.2KW
 Air Pressure 0.65Mpa
 Air Consumption  0.3m³/min
(Standard machine, no additional function)
 Body Dimension  1770*600*1230mm
 Packing Dimension  1860*710*1550mm
(Export non-fumigation wooden case)
Combined Parts:

The elevator

The dose and filling machine

The work platform

The finished product conveyor
