Strip Candy Sorting Tray Packaging Machine

Application:

Suitable for pack various kinds of regular objects into pillow bag or gusseted bag. the object like metal parts, industrial parts, hardware accessories, toys and other conventional items.

Details:


Model:LP-250
Speed:40-230bag/min
Packing Size: 4090x680x1420mm
Control system: PLC
Power supply: 220V, 50/60Hz, 2.4kw
Product Height:Max.45mm
Equipment material: 304
Weight: About 500kg

Description of the main packaging process: Box feeding-weighing-feeding-out of box

Tel/Whtasapp: +86 17388602385
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

The food contact surface is made of SUS304 stainless steel;

All bearings are imported from the country (Harbin and NSK);

Imported food-grade anti-bacterial PU tape

All other plates and shafts are immersed in nickel and aluminum profiles are oxidized and sandblasted;

All stainless steel parts are laser cut, drawn and deburred.

The brackets and shields are painted with carbon steel.

Simple driving system,reliable working,convenient maintenance.
Application:

Automatic Lemon Cake Horizontal Flow Wrap Machine, Suitable for packing all kinds of strips, rods and other bulk conventional shapes into one bag. Such as lemon cakes, waffles, Swiss rolls, moon cakes, etc.
Samples:


Specification:
Model LP-250 LP-320B LP-320D
Film Width Max.250mm Max.320mm Max.320mm
Bag Length 65-190 or 120-280mm 65-190 or 120-280mm 90-220 or 150-330 mm
Bag Width 30-110mm 50-160mm 50-160mm
Product Height Max.40mm Max.40mm Max.55mm
Film Roll Diameter Max.320mm Max.320mm Max.320mm
Packaging Speed 40-230bag/min 40-230bag/min 40-230bag/min
Machine Size 220V, 50/60Hz, 2.4kw 220V, 50/60Hz, 2.6kw 220V, 50/60Hz, 2.6kw
Machine Weight 4090x680x1420mm 4090x720x1420mm 4090x720x1420mm
Power Specifications About 500kg About 550kg About 550kg
Applicable Membrane Material OPP/CPP,OPP/PE,PET/PE OPP/CPP,OPP/PE,PET/PE OPP/CPP,OPP/PE,PET/PE
Combined Parts:

Lateral feed device

Straight feed device

Belt material conveyor

End sealing auxiliary conveyor

Auxiliary material feeding device

Materia cut prevent device

Perforating device

Angle folding device

Date Printer

Labelling machine
