Automatic Pillow Bag Biscuit Popsicle Colorful Sponge Flow Wrapping Packing Machine

Application:

Mainly designed for packing various regular and solid products such as sponge, soap, cookie, towel, popsicle, vegetable, fruit, noodles, cake, bread, biscuits, candy, chocolate, daily necessities, face mask, chemical product, hardware and so on.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.;
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Working Process:
Inquiry
Features:

1. Three servo motor controls, no empty bag.

2. Adjustable bag former, suitable for different sizes of products.

3. Suitable for regular products, such as biscuits, bread, masks, etc.

4. The function of preventing empty packets.

5. Up to 120 packets per minute.
Application:

Mainly designed for packing various regular and solid products such as sponge, soap, cookie, towel, popsicle, vegetable, fruit, noodles, cake, bread, biscuits, candy, chocolate, daily necessities, face mask, chemical product, hardware and so on.
Videos Introduction:
Specification:
Model LP-250 LP-350 LP-450 LP-600 LP-700 LP-800 LP-900
Film width Max250mm Max350mm Max450mm Max600mm Max700mm Max.800 mm Max.900mm
Bag length 65-190mm or120-280mm 65-190mm or120-280mm 150-450mm 160-500mm 180-600 mm 210-650mm 240-700mm
Bag width  30-110mm  50-160mm 50-180mm 100-280mm 100-330 mm 120-350mm 150-400mm
Product height Max.40mm Max.40mm Max.75mm Max.110mm Max.110 mm Max.130 mm Max.150mm
Film roll diameter  Max.320mm
Packaging rate 40-230 bags/min 40-180bags/min 30-150Bags/min 20-150 bags/min 20-130 bags/min 20-120bag/min 20-100 bags/min
Power 220V,50/60Hz,2.4kw 220V,50/60Hz,2.6kw 220V,50/60Hz,2.8kw 220V,50/60Hz,2.8kw 220V,50/60Hz,2.8kw 220V,50/60Hz,4.5kw 220V,50/60Hz,4.5kw
Machine size (L)3770*(W)720*(H)1420mm (L)4030*(W)770*(H)1420mm (L)4030*(W)820*(H)1420mm (L)4030*(W)970*(H)1500mm (L)4030*(W)980*(L)1500mm (L)4100*(W)1170*(H)1550mm (L)4300*(W)1270*(H)1550mm
Machine quality About 500kg About 580kg About650kg About680kg About720kg About800kg About 850kg
Remarks optional air filling device)/optional angle folding)
Film material) OPP/ PE/ PVC/ OPP/ CPP/ PT/ PE/ KOP/ CPP/ Aluminum Coating Film/ Aluminum Film
Working Process:

1.Sponge Feeder

2.Transport the sponge

3.Pull the packing film

4.Seal the sponge into bag.
