Automatic Candy Pillow Pack Machine LP-250C

Application:

Packaging various kinds of regular objects like Candy, chocolate, chewing gum and suit for square, spherical, disc, cylindrical, kinked, oval and all kinds of special-shaped candies and solid blocks.

Details:


Model:LP-250/ 350/ 450/ 600/ 700/ 800/ 900
Speed:50-900 bags/min
Bag Size: W: 10-50mm; L: 10-30mm
Film width: 50-120mm
Product height: 4-25mm
Film roll diameter:320mm
Packaging rate: 50-900 bags/min
Tel/Whtasapp: +86 17388602385
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

Servo motor control, Bag length can be set and cut in one step,saving time and film.

Interface features easy and quick setting and operation.

Self failure diagnosis, clear failure display.

High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.

Temperature independent PID control, more suitable for packaging different materials.

Positioned stop function, without sticking knife or wasting film.

Simple driving system, reliable working, convenient maintenance.

All control is realized through software,easy for function adjusting and technical upgrade.
Application:

Suitable for pillow packing of conventional items such as hardware accessories parts, soap, bread, pancake, biscuit, cake, rusk, bun, etc.
Samples:


Specification:
Type LP-250C
Film width 50-120mm
Bag length 10-50mm
Bag width 10-30mm
Product height 4-25mm
Film roll diameter 320mm
Packaging rate 50-900 bags/min
Power 380v,50/60 Hz ,3.2kw,
Machine size 3850x1100x1800mm
Machine quality 720kg
Film material OPP、PE、PVC、OPP/CPP、PT/PE、KOP/CPP Aluminum Coating Film/ Aluminum Film
Combined Parts:

Belt material conveyor

End sealing drag chain

Auxiliary material feeding device

Material cut prevent device

Perforating device

Angle folding device

Date printer

Labeling machine

Thermal transfer code printer

Air charging system

Cutting stop

Prevent empty package
