Full Automatic Heathcare Supplement Tablets Vitamin Casuple Counting Bottle Filling Capping Labeling Machine Line

Application:

This counting filling line From sorting bottles to labeling stickers, the automatic counting line includes everything you need to get your capsules or tablets into a container. It is intended to operate completely automatically, with only one person monitoring the entire operation.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.;

Features:

1.All the machines will run synchronously through the PLC system after they are connected, and ensure the stability of long-term operation..

2.The core part of each machine in the production line adopts a modular design to achieve rapid adjustment and independent use.

3.The entire counting production line can achieve simple and rapid assembly and separation.

4.The outer frame of the complete set of machines is made of excellent 304 stainless steel, and the material contact part is made of 316 stainless steel, which fully meets GMP requirements.

Application:

This counting filling line is suitable for fully automatic bottle Unscramble, counting, filling, sealing, capping, labeling and other workflows (optional boxing) of various granular products. Such as tablets pills gummy capsule chewing gum softgel etc.

Videos Introduction:

Specification:

Model	Application	Capacity	Power	Gas consumption	Overall Dimension
8 channel counting line	Tablets and pills below φ20 Capsule No.000-5 (customizable channels)	20-40 bottles/min	220V /6.75KW	1.0m³ /min	100008502500mm
16 channel counting line		50-80 bottles/min	2.0V; o.75Kv.	1.2m³ /min	115008502500mm
32 channel counting line		100+ bottles/min	220V/8KW	1.4m³ /min	125000* 850*2500mm

Composition:

1. Bottle Unscrambler: Organzie messy bottles → 2. Counting Machine: Counting pills and filling into bottle;→ 3. Desiccant Inserter: Stuff the desiccant into the bottle;→ 4. Capping Machine: Tighten the cap with anti-lock prevents excessive damage;→ 5. Alu-foil Sealing Machine: Seal the bottle lip with aluminum foil;→ 6. Labeling Machine: Stick a label on the body of the bottle automatically;→ 7. Bottle Unscrambler: Organzie messy bottles;→ 8. Counting Machine: Counting pills and filling into bottle;→ 9. Desiccant Inserter: Stuff the desiccant into the bottle;→ 10. Capping Machine: Tighten the cap with anti-lock prevents excessive damage;→ 11. Alu-foil Sealing Machine: Seal the bottle lip with aluminum foil;→ 12. Labeling Machine: Stick a label on the body of the bottle automatically.
