Automatic Medicinal Powder Stick Bag Filling And Packaging Boxing Machine Line

Application:

Medicinal Powder Stick Bag Filling And Packaging Boxing Machine Line, Applicable for packing powder materials and granular materials such as coffee powder, medicinal powder,chemicals powder, sugar, salt, coffee, MSG, seasoning,etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

E-mail: info@landpacking.com

Tel/Whtasapp: +86 18688215960

Chat Now Send Email View video

Features:

Application:

Videos Introduction:

Specification:

Packing type:

Features:

1. High production efficiency, the speed of 6 rows can reach 120~180 packages per minute, which increases production capacity and saves manpower;

2. High degree of automation: filling, loading, printing batch number, easy tearing, finished product bag output in one go, quick and easy adjustment;

3.6 Servo motor system control, precise measurement, accurate film pulling and film feeding;

4. Equipped with a dust suction device to prevent dust inclusion in the powder.

Application:

Medicinal Powder Stick Bag Filling And Packaging Boxing Machine Line, Applicable for packing powder materials and granular materials such as coffee powder, medicinal powder,chemicals powder, sugar, salt, coffee, MSG, seasoning,etc.

Videos Introduction:

Specification:

Multi Lane Stick Packing Machine Parameters
Model	LD-280BF	LD-560BF
Lane number	4-6 Line	8-12 Line
Filling Method	1.Volumetric cup; 2. Weigher
Capacity	Max.35 cycle/ min
Sachat Size	L:50-180mm; W:17-30mm	L:50-180mm; W:17-30mm
Film weidth & Thickness	Max.280mm, 0.07-0.10mm	Max.560mm, 0.07-0.10mm
Sealing type	Back sealing/Stick bag	Back sealing/Stick bag
Cutting type	1.Straight cutting; 2.Zig zag cutting; 3.Round cutting; 4.Irregular
Air & Powder	0.8Mpa 0.8m3/min; 3.5kw	0.8Mpa 0.8m3/min; 5.5kw
Dimension & weight	13859182005mm;350kg	168513002005mm;550kg

Fully Automatic Cartoning Machine Parameters
Max box size	350mm320mm100mm（LWH）
Min box size	70mm40mm15mm（LWH）
Speed	60-100 box/min
Available paper	300-350 g/m³
Power supply	220V/50HZ
Max power	About 1.2KW
Weight	1500kg
Air pressure	0.6-0.8MPa
Air consumption	200-260L/min
Overall dimension	4000mm1580mm1850mm
customizable

Packing type:

1. Sealing type: Back sealing/Stick bag;

2.Cutting type: Straight cutting; Zig zag cutting; Round cutting; Irregular
