Automatic 4 Heads Piston Pump Glass Bottle Paste Filling Machine Line

Application:

Suitable for packing all kinds of liquid, fluid and paste material, such as paste, edible oil, sauce, oil, honey, daily necessities, medicine, etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Optional:
Inquiry
Features:

1.System control, data can be adjusted and stored, simple operation.

2.Use drip proof stainless steel filling head and photoelectric induction.

3.Tracking capping head is controlled by servo motor stable performance and reliable operation.

4.The electric eve uses advanced photoelectricity Easy adjust the position and angle. fast and stable.

5.The connecting shaft connects the motor shaft and the filling support shaft. Stable and easy to install.
Application:

This machine adopts piston pump and rotary valve, suitable for filling all kinds of thick & sticky material: In food industry like, tomato paste, chilli sauce, paste, butter, ketchup lunch meat, mayonnaise, marmadele, etc.
Videos Introduction:
Specification:

Model

LD-ALF01

Filling Range

50-1000ml(Customizable)

Filling Speed

15-50 bottles/min

Measurement accuracy

±1%

Power

2 KW

Working power supply

220V, 50Hz

Working pressure

0.6-0.8MPa

Weight

500kg

Size

L4000*W1320*H2090(mm)

Optional:

1.Bottle unscrambler

2.Capping Machine

3.Labeling Machine
