Full Auto Mixed Product VFFS Packaging Machine With 32 Head Weigher

Application:

Suitable for packing all kinds of mixed granule product, sheet material, strip material and abnormity material which such as candy, sunflower seeds, peanut, nuts, beans, potato chips, popcorn, almond, dry fruit, vegetable salad (shreded or sllices vegetables, like iceberg lettuce, cabbage, romain, spring onion and leek ect.), frozen food, jelly, biscuit, chocolate, filbert, corn, pet food, dilatant foodstuff, hardware and plastic can be weighed by the ration.

Details:

Model:LD-420

Film Thickness:0.04-0.08mm

Bag Length:80-300mm

Bag Width:60-200mm

Film Roll Diameter:Max.320mm

Pakaging Rate:5-60bag/min

Film Width:Max.420mm

Measurement Range:150-1500ml

E-mail: info@landpacking.com

Tel/Whtasapp: +86 18688215960

Chat Now Send Email View video

Features:

Application:

Samples:

Specification:

Combined Parts:

Features:

The machine adopts high precision servo film transport system, PLC Program Control,developed touchable Human-machine Interface of Advanced Automatic Positioning,Photoelectric Tracking,Digital Temperature Control,etc.

Operation is more Simple,perfect.It is the first choice of food packaging industry to Improve the production efficiency, reduce Labor Intensity, improve the grade of packaging equipment.

Transverse and longitudinal sealing Temperature Control independently,suitable for PE/polyethylene,PE/aluminum plating, pet/PE, pp,and other heat-ealing packaging materials, etc.

It completes the whole procedure of filling,measuring,bagging,date printing,charging(exhausting),product out-putting automatically.

High precision, high efficiency without crash the materials.

Packaging style diversified,back sealing,gusset bag,continuous bags,punching,etc.

Work environment quiet, low noise, saving energy.

A complete set of equipment is economical.

Application:

It's suitable to use in packaging the high accuracy and easy fragile material,such as: puffy food, crispy rice, jelly, candy, pistachio, apple slices, dumpling, chocolate, pet food, small hardwares, medicine, etc.

Samples:

Specification:

Model	LD-420	LD-520	LD-720	LD-900	LD-1050	LD-1200
Film Thickness	0.04-0.08mm	0.04-0.12mm	0.04-0.12mm	0.04-0.12mm	0.04-0.12mm	0.04-0.12mm
Bag Length	80-300mm	80-350mm	100-500mm	100-600mm	100-800mm	100-1000mm
Bag Width	60-200mm	100-250mm	180-350mm	260-430mm	290-505mm	290-580mm
Film Roll Diameter	Max.320mm	Max.320mm	Max.320mm	400mm	400mm	400mm
Pakaging Rate	5-60bag/min	5-60bag/min	5-55bag/min	5-20bag/min	5-20bag/min	5-20bag/min
Film Width	Max.420mm	Max.520mm	150-Max.720mm	Max.900mm	Max.900mm	Max.1200mm
Measurement Range	150-1500ml	5-2000ml	4000ml	1-25L	1-25L	1.5L-45L

Combined Parts:

LD series main frame

multi heads weigher

Z type bucket elevator

Vibration feeder

Supporting platform

Product conveyor
