Multifunction Inclined Type Packaging Machines

Application:

Suitable for heavy and bulky fragile bulk goods packaging such as iron nails, fish, meat, chicken, fish, steak, meatloaf, etc.


Details:


Model:LD-420
Film Thickness:0.04-0.08mm
Bag Length:80-300mm
Bag Width:60-200mm
Film Roll Diameter:Max.320mm
Pakaging Rate:5-60bag/min
Film Width:Max.420mm
Measurement Range:150-1500ml
Mobile Phone/Whatapp: +86 13242108152
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

The equipment uses an external film release mechanism to make the installation of packaging film simpler and easier.

The pull film mainly uses servo motor control to achieve high-precision packaging positioning and accurate packaging size;

In the process of vertical sealing, automatic error correction can be performed, which can greatly reduce labor intensity;

This tiltable packaging can better protect the fragile items and the box-shaped packaging bag has a good molding effect and a beautiful appearance;

The reliable and stable PLC control and color touch screen are used to make the packaging process complete smoothly at one time.

Application:

Suitable for heavy and bulky fragile bulk goods packaging such as iron nails, fish, meat, chicken, fish, steak, meatloaf, etc.
Samples:

Specification:
Model LD-420 LD-520 LD-720 LD-900 LD-1050 LD-1200
Film Thickness 0.04-0.08mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm
Bag Length 80-300mm 80-350mm 100-500mm 100-600mm 100-800mm 100-1000mm
Bag Width 60-200mm 100-250mm 180-350mm 260-430mm 290-505mm 290-580mm
Film Roll Diameter Max.320mm Max.320mm Max.320mm 400mm 400mm 400mm
Pakaging Rate 5-60bag/min 5-60bag/min 5-55bag/min 5-20bag/min 5-20bag/min 5-20bag/min
Film Width Max.420mm Max.520mm 150-Max.720mm Max.900mm Max.900mm Max.1200mm
Measurement Range 150-1500ml 5-2000ml 4000ml 1-25L 1-25L 1.5L-45L
Combined Parts:


LD series main frame

10 heads weigher

Z type bucket elevator

Vibration feeder

Supporting platform

Product conveyor
