High Speed Premade Pouch Rotary Filling Sealing Machine

Application:


Suitable for automatic packing for grain and solid food, such as beans, nuts, dry fruits, candy, tomato sauce, peanut buttercereal, chocolate, biscuit, peanut, capsule, seeds, chemicals,milk powder, coffee powder, sugar, etc.


Details:


Model:LD-8300
Pouch Size (mm):W: 200~300mm, L: 100~350mm.
Packing Capacity: 30~40bags/min(the speed depends on type of products), 25~35bags/min (for zipper pouch)
Pouch Size: W: 200~300mm, L: 100~350mm.
Filling Volume; 10-2500g(Depend on type of products)
Total power & 4KW(220V/380V,3PH,50HZ)
Tel/Whtasapp: +86 17388602385
Features:
Application:
Samples:
Specification:
Combined Parts:
Inquiry
Features:

Easy to operate, adopt advanced PLC from Germany Siemens, mate with touch screen and electric control system, the man-machine interface is friendly.

Frequency conversion adjusts the speed: this machine uses frequency conversion equipment, can be adjusted within the range according to the needs of reality in production.

Automatic checking: no pouch or pouch open error, no fill, no seal. the bag can be used again, avoid wasting packing materials and raw materials.

The width of the bags could be adjusted by electrical motor. Press the control-button could adjust the width of clips, easily operate, and save time.

The packing materials loss low, what this machine is used the preformed bag, the bag pattern is perfect and has a high quality of the sealing part, this improved the product specification.

Product or packing bag contact parts adopt stainless steel or other materials which accord with the food hygienic requirements, guarantee hygiene and security of the food.
Application:

Liquid/paste type: detergent,e, soy sauce, rice vinegar, fruit juice, beverage, tomato sauce, peanut butter, jam, chili sauce, bean paste,etc..

Block material: bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuit, peanut, etc.

Granular type: crystal monosodium glutamate, granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer,etc.

Powder type: milk powder, glucose, monosodium glutamate, seasoning, washing powder, chemical materials, fine white sugar, pesticide, fertilizer, etc.
Samples:
Specification:
Model LD-8200LS/ 8240LS/ 8300LS
Bag Size W: 100-300mm L: 100-450mm
Filling Volume 10-2500g (Depending on type of products)
Capacity 25-60 bags/min (The speed depends on type of products and packaging material used)
Package Accuracy Error≤±1%
Compress Air Requirement ≥0.8m³/min supply by user
Combined Parts:

The elevator

multihead weigher

The work platform

The finished product conveyor
