Coffee Powder Quad Seal Bag/ Block Bottom Pouch Packing Machine

Application:

This machine is suitable for four-side sealing bag packaging of coffee powder, making the packaging more beautiful.

Details:

Model:LDB-420

Film Width:150-Max.420mm

Bag Length:80-280mm

Bag for Front width:80-132mm

Bag for Side width:20-66mm

Film Roll Diameter:Max.320mm

Film Thickness:0.04-0.12mm

Packaging Rate:10-40bag/min

Power:220V 50/60Hz 2.8KW

Machine Size(L*W*H):1390*1155*1800mm

Machine Quality:About 600kg

Option device:air filling device, hole-punching device.

Mobile Phone/Whatapp: +86 13242108152
Features:
Sample video:
Samples:
Specification:
Combined parts:
Inquiry
Features:

New design with perfect fashion,more reasonable structure,more advanced technology..

Imported PLC control system,colorful touch screen,easy operation, intuitionistic efficient.

Standard positioning with imported servo film transporting system and mark sensor,Super excellent capability for complete machine,perfect packaging.

With auto warning protection function to minimize loss.

Various kinds of bag, it could provide the pillow bag, angle fold bag, hang hole bag,.link bag,etc.

Automatic correct function, save time, labor, and film, the operation more intelligent.

Adopt external film feeding mechanism.Film setting be more easy and quick.
Sample video:
Samples:

Specification:
Model LDB-420 LDB-520
Film Width 150-Max.420mm 250-Max.520mm
Bag Length 80-280mm 80-350mm
Bag for Front width 80-132mm 80-150mm
Bag for Side width 20-66mm 35-90mm
Film Roll Diameter Max.320mm Max.320mm
Film Thickness 0.04-0.12mm 0.04-0.12mm
Packaging Rate 10-40bag/min 10-40bag/min
Power 220V 50/60Hz 2.8KW 220V 50/60Hz 3KW
Machine Size(L*W*H) 1390*1155*1800mm 1492*1255*2184mm
Machine Quality About 600kg About 700kg
Option device air filling device, hole-punching device. air filling device, hole-punching device.

Combined parts:

ZV series main frame

Screw metering machine.

Screw infeed conveyor

Product conveyor
