Automatic Ground Coffee Doypack Packing Machine

Application:

It is suitable for automatic packing for Powder: milk powder, coffee powder, food additives, condiments, tapioca powder, coconut powder, pesticide powder, fertilizer granules etc.

Details:


Brand:Landpack
Model:LD-8200DS/ 8240DS/ 8300DS
Bag size: W: 70-200mm, L: 100-250mm
Filling Range: 10-1000g/20-2500g
Packing speed: 40-60bag/min
Tel/Whtasapp: +86 17388602385
Features:
Sample video:
Samples:
Specification:
Main Process:
Inquiry
Features:

Automatic rotary packing machine adopt precision indexing device and PLC to control each action and working station to make sure the machine operates easily and does accurately.

The speed of this machine is adjusted by frequency conversion with the range, and the actual speed depends on type of products and pouch.

Automatic checking system can check bag situation, filling and sealing situation.

The system shows no bag feeding, no filling and no sealing. no bag opening/opening error, no filling and no sealing no filling, no sealing.

The product and pouch contact parts are adopted stainless steel and other advanced material to guarantee the hygiene of products.

We can customize the suitable one for you according to your requiredment.

Just Tell us : Weight or Bag Size required.
Sample video:

Samples:

Specification:
Model LD-8200/LD-8250
Packing material 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc
Size W:70-200/100-250
Filling range 10-1000g/20-2500g
Packing speed 40-60bag/min(speed is determined by the product filling quantity)
Average precision ≤ ±1%
Total power 2.5KW
Dimensions 1900mm X 1570mm X 1700mm(L*W*H)
Work flow giving bag→coding →opening →filling 1 →filling 2→ auxiliary→ exhaust→heat sealing→ .forming and output product
Main standard parts 1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system
Main Process:

Bag giving

Date coding

Bag opening

Filling and vibrating1

Filling and vibrating 2

Product setting after filling by vibrating

Heat sealing

Forming and product output
