Automatic Multi Lane Peanut Butter Sachet Counting Packaging Cartooning Machine

Application:

Automatic sachet counting packing cartooning machine is suitable for all kinds of paste, viscous liquid packaging, such as peanut butter, ketchup, jam, chili sauce, honey, pizza sauce, peanut butter, tartar sauce, chocolate sauce, chili sause, cream, liquid butter, juice, shower gel, shampoo etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Tel/Whtasapp: +86 18688215960
Features:
Application:
Videos Introduction:
Specification:
Optional:
Inquiry
Features:

1. Heating and stirring function ensures uniform heating and mixing of the material.

2. Front water inlet pipe is automatically connected, ensuring a stable and continuous flow of water for efficient operation.

3. Electric counting eyes detect the number of objects being fed into the machine and stop the machine once the set number is reached, reducing the risk of overflow and ensuring accurate counting.
Application:

Automatic sachet counting packing cartooning machine is suitable for all kinds of paste, viscous liquid packaging, such as peanut butter, ketchup, jam, chili sauce, honey, pizza sauce, peanut butter, tartar sauce, chocolate sauce, chili sause, cream, liquid butter, juice, shower gel, shampoo etc.
peanut butter packaging machine
Videos Introduction:
Specification:

Model

LD-480Y LD-720Y LD-960Y
Track Number 4-6 Track 4-10 Track 4-12 Track
Filling Method 1. Piston pump; 2. Peristaltic Pump
Capacity Max.40 cycles/min
Sachet Size L: 45-120mm; W: 35-60mm L: 45-120mm; W: 35-90mm L: 45-120mm; W: 35-120mm
Film Width & Thickness Max.480mm; 0.07-0.1mm Max.720mm; 0.07-0.1mm Max.960mm; 0.07-0.1mm
Sealing Type 3/4 sides sealing 3/4 sides sealing 3/4 sides sealing
Cutting Type 1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting
Air & Power 0.8 mpa, 0.8m³/min; 2.8kw 0.8 mpa, 0.8m³/min; 4.1kw 0.8 mpa, 0.8m³/min; 5.5kw
DIM & WT 950*1470*1750mm; 300kg 1153*1654*1750mm; 400kg 1415*1686*2130mm; 500kg
Optional:

1.Air-sharf roll film device

2.Multi-heads Ribbon date printer to print date info on each lane

3.Material tank includes the level sensor

4.Stirring & Heater

5.Filling nozzle includes the anti-leaking device
